During modeling different complex joints were simplified. This modeling gave us a rough idea about how it will look after fabrication and this also helped us in reviewing our design again and again to make it more accurate. After this all our detailed diagrams, we used for the next stage i. The person sitting on the wheelchair has a joy stick on his right side. For example if person pushes joy stick forward then wheelchair will move in the forward direction.

Similarly if person pushes joy stick backward then wheelchair will move in the backward direction. Joy stick can be move at any angle. The amount by which the joy stick is moved is proportional to the amount of voltage signal send to the internal circuitry and then that specified voltage signal is translated into a specific speed. This wheelchair is rare wheel driven and it has differential drive.

Fig In order to make wheelchair autonomous, we shiftedits control from joystick to LabView.

In this case hardware is our wheelchair and software is LabView. This LabView program was made to control wheelchair motion. Previously this was controlled by joystick.

A continuous while loop is implemented so that a required value is being sent to wheelchair at all times. There is a stop button in the program by which code can be terminated at any time. Actually an angular velocity and a forward velocity values are given to the program This conversion is done by two functions; one made for forward speed and another for angular speed.

This function is made by using straight line equation i. Constant voltages of 1. RPM of the rare wheels were measured by the tachometer. Then velocity was calculated on the basis of rpm.

Final Year Projects For Mechanical Engineering Reports

The graph above shows the trend of voltage vs. We gave wheelchair different sets of voltages through LabView and then measured the resultant speed of wheelchair by measuring rpm of its rare wheels. Following conclusions can be drawn from the above graph:. There is a voltage window where wheelchair does not move due to inertia and that is 1.

The main purpose of drawing this graph was to know exactly about the speed output when a specified voltage is provided. This knowledge helped during the developing of obstacle avoidance and navigation codes and it also helped us during real-time wheelchair testing phase. Obstacle Avoidance is a means of a robot being able to move around in an unknown environment without unknown obstacles coming in its path. It is one of the most important aspects of mobile robotics. According to Seigwart et al, local obstacle avoidance focuses on changing the robots trajectory as informed by its sensors during realtime robot motion.

The resulting function is both a function of robots current or recent sensor readings and its goal position and relative location to the goal position. In developing our obstacle avoidance algorithms for the Autonomous Robotic Wheelchair, we were able to benefit significantly from the work completed in lieu of our MRDS semester project for our Intro to Mechatronics and Robotics class taught last semester by Dr.

Yasar Ayaz and Dr. Umar Gillani. We studied and practiced coding for primarily the obstacle avoidance algorithms presented in the Introduction to Autonomous Mobile Robotics by Seigwart et al.

For example:. The Bug Algorithm is the simplest most intuitive obstacle avoidance algorithm. The basic idea is to follow the contour of the obstacle in order to circumnavigate around it. It has two different forms Bug1 and Bug2. In Bug1 algorithm, the robot fully circles around the obstacle and then moves along the line of shortest path towards the endpoint.

This is the obstacle avoidance technique we have been able to implement in our code. With Bug2 algorithm, the robot starts to follow the objects contour but departs immediately when it able to move directly towards the object.

This would have been more efficient and future coding on the Autonomous Wheelchair could attempt to develop this. The VFH algorithm generates a polar histogram, in which the X-axis represents the angle alpha at which the obstacle was found, and the Y-axis represents the probability grid that there is an obstacle in that direction based on the occupancy grids cell values. However, we did not pursue it further due to its redundancy with the potential field path-planning algorithm which we were working on implementing at the time.

There are a handful of other promising obstacle avoidance algorithms presented in Seigwart et al, however we were able to investigate and understand only the ones discussed. Our obstacle avoidance functions attempt to update motor speeds if there is an obstacle to be avoided. We update the function just before sending data to the motors.

Thus, obstacle avoidance overwrites onto our navigation behavior for the robot. Once the obstacle is no longer in its way, the robot moves along as it was. This allows us to transition from any navigation behavior into obstacle avoidance and then back again, as per the requirements of our control structure.

We wrote three distinct obstacle avoidance codes for the Autonomous Robotic Wheelchair. These are discussed as follows:. This was the first obstacle avoidance code that we developed. It created and initialized two variables newspeed and newturnrate within a continuous for loop.

GetMinRight and GetMinLeft in order to see to the left and right of the robot for obstacles.
